£67.10 (excl. VAT)
Double-Glazed Aluminium Base / Wall Channel
The 54-2P is an aluminium channel, consisting of a chair and two beads. Designed for use as a base and wall channel in double-glazed systems, it is made from high-quality Aluminium 6063 T6, offering durability and a strong, reliable framework for installations.
Dimensions: 54mm wide, 25mm high, and 3000mm in length.
Includes a pre-inserted Q-Lon acoustic seal, accommodating glass thicknesses of 10mm/10.8mm or 12mm/12.8mm. The 54-2P channel is fully compatible with all components in the 54mm system and provides excellent acoustic insulation, making it ideal for high-performance, double-glazed applications in both commercial and residential settings.
This aluminium section for glass partition ensures a seamless fit with double glazing frames and is perfect for use with aluminium channel for 10mm glass or 12mm glass, as well as aluminium u channel for 10mm glass and aluminium u channel for 12mm glass. It is also a suitable choice for creating sleek, modern aluminium channel for glass doors.
Available in RAL 9005, 9010, 9006, 7016. For bespoke colours, please get in touch (POA).
The 54-2P aluminium section for glass partition is a high-performance base and wall channel designed for use in double glazing aluminium frames. Built from durable Aluminium 6063 T6, it offers structural integrity and acoustic performance, making it ideal for modern architectural glazing solutions.
This complete profile consists of a chair and two aluminium beads, providing both strength and precision. Measuring 54mm wide x 25mm high and supplied in 3000mm lengths, the 54-2P is suited for use in residential and commercial double glazing frames where stability, sound insulation, and visual minimalism are essential.
Equipped with a pre-inserted Q-Lon acoustic seal, this aluminium channel for 10mm glass and 12mm glass accommodates glass panels of 10mm/10.8mm and 12mm/12.8mm. It ensures superior acoustic control, making it a reliable solution for offices, meeting rooms, and premium residential interiors.
Whether you need an aluminium u channel for 10mm glass, 12mm glass, or an aluminium channel for glass doors, the 54-2P delivers consistent performance across all configurations.
The 54-2P integrates effortlessly with other components in the 54mm series, including the 54-Box, 54-DF, 54-Deflection, 54-Deep, and 54-1P, supporting seamless transitions throughout the full partition system.
This makes it the ideal profile for comprehensive double glazing aluminium frames, supporting creative freedom without compromising technical performance.
Available finishes: RAL 9005, 9010, 9006, 7016.
For bespoke colours, please contact us (POA).
